>> SGDV-180A01A000FT001 Best use servo unit
SGDV-180A01A000FT001 Best use servo unit
SGDV-180A01A000FT001 Introduce |
SGDV-180A01A000FT001 Catalog / Manual / Instructions / Software download
Yaskawa SGDV-180A01A000FT001 Manual And Instructions
SGDV-180A01A000FT001 Design and MaintenanceUSER'S MANUAL
Yaskawa SGDV-180A01A000FT001 Product information and technical parameters：
Brand: Yaskawa
Name: Best use servo unit
Model: SGDV-180A01A000FT001
High performance, use the best type of servo unit (purpose type).
Maximum applicable motor capacity: 2.0kw.
Power supply voltage: three phase AC200V.
Interface: analog voltage, pulse sequence type (rotary servo motor).
Design sequence: A.
Hardware specification: base mounting type (standard).
Function: vibration suppression function upgrade.
Use the best type of sigma -V-FT series
According to different uses, there are 5 equipped with a convenient function of the servo unit models.
FT001 (vibration suppression function to upgrade specifications): by strengthening the vibration suppression function, shorten the positioning time.
FT003 (pressure feedback function): high precision pressure control, to promote the high performance of the device.
FT005 (support for rotary table purposes): with the rotation of the coordinate function and fixed point through the output function, can be smooth and high-precision control of rotary table.
FT006 (fixed point through the output function): no need to pass through the upper device can be set through the output (Chu Fa).
FT008 (absolute value system support): the absolute value of the system can be constructed by any upper controller.
...More relevant models >>>>
