YASKAWA YASKAWA SGM7G-1EAFC6S Price

SGM7P type (rated speed: 3000r\/min) of inertia and flat servo motor in non speed reducer.
Rated output: 0.4kw.
Power supply voltage: AC200V.
Serial encoder: 24 bit absolute value type.
Design sequence: IP65.
Shaft end: straight shaft, no keyway.
Optional parts: no purchase pieces.
Yaskawa servo motor, also known as YASKAWA Yaskawa servo motor,
Origin of Japan, in Shenyang, China, Jiading, Shanghai also has a factory,
Is to make the position of the object, the position, the state and other output controlled,
Automatic control system capable of following an arbitrary change of an input target value (or a given value) SGM7G-1EAFC6S
It is divided into AC servo motor and DC servo motor,
In the domestic semiconductor, liquid crystal manufacturing devices, electronic components packaging equipment, machine tools and general machinery has been widely used in.
As a leading enterprise for the first time Yaskawa servo drive, put forward the concept of "mechatronics",
Now has become a universal termEquipped with DeviceNet communication function type servo unit (servo controlled power supply drive type)
Maximum applicable motor capacity: 5.0kw.
Power supply voltage: three phase AC400V.
Interface: instruction selection and installation (linear servo motor).
Matching (hardware): paint.
Matching (software): standard.
Matching (parameter): standard.
Optional modules: DeviceNet module (servo control power driver) + full closed loop module.
Communication specifications for DeviceNet based on open field network.
The combination of the DeviceNet controller and the V can be used to implement motion control in a simple way.
Can make use of the city''s rich DeviceNet support software.
Can use the upper controller to manage the servo information.
Through the network from the host controller to monitor the running status of the servo drive, alarm information.
Using the upper controller to manage the servo information, which can improve the maintenance (shorten the debugging time, improve the efficiency of maintenance operations).
Save wiring, reduce the cost and improve the reliability.
Because the upper controller and the servo unit are connected through the communication network, the connection is greatly saved.
Built in rich positioning function.
Can be from the upper controller (PLC or computer) to carry out a variety of simple positioning action.
Equipped with simple positioning, continuous rotation, and return to the origin of continuous rotary motion positioning, running and other rich positioning function.
SGM7G-1EAFC6S Operation manual / Instructions / Catalog download link: /searchDownload.html?Search=SGM7G-1EAFC6S&select=5
